我正在使用Tensorflow 2.1.0
构建一个自定义模型 (SegNet)。
第一个问题是需要重复利用最大池化操作的索引,如论文所述。 由于这是编码器-解码器架构,因此需要在解码器中上采样特征图并保留相应索引的值。
然而,在TF中,tf.keras.layers.MaxPool2D
层默认不导出这些索引(例如PyTorch中的导出)。
为了获取最大池化操作的索引,需要使用tf.nn.max_pool_with_argmax
。
但是,这个操作返回的索引(argmax)是扁平化的格式,需要进一步处理才能在网络的其他部分中使用。
为了实现一个执行MaxPooling2D并导出这些索引(扁平化)的层,我在keras中定义了一个自定义层。
class MaxPoolingWithArgmax2D(Layer):
def __init__(
self,
pool_size=(2, 2),
strides=2,
padding='same',
**kwargs):
super(MaxPoolingWithArgmax2D, self).__init__(**kwargs)
self.padding = padding
self.pool_size = pool_size
self.strides = strides
def call(self, inputs, **kwargs):
padding = self.padding
pool_size = self.pool_size
strides = self.strides
output, argmax = tf.nn.max_pool_with_argmax(
inputs,
ksize=pool_size,
strides=strides,
padding=padding.upper(),
output_dtype=tf.int64)
return output, argmax
显然,这一层在网络的编码部分中使用,因此需要一个相应的解码层来执行反向操作(UpSampling2D),利用索引进行操作(有关此操作的更多详细信息请参见论文)。
经过一些研究,我发现了遗留代码(TF<2.1.0),并对其进行了调整以执行该操作。但无论如何,我并不完全相信这段代码能够很好地工作,事实上有一些我不喜欢的东西。
class MaxUnpooling2D(Layer):
def __init__(self, size=(2, 2), **kwargs):
super(MaxUnpooling2D, self).__init__(**kwargs)
self.size = size
def call(self, inputs, output_shape=None):
updates, mask = inputs[0], inputs[1]
with tf.name_scope(self.name):
mask = tf.cast(mask, 'int32')
#input_shape = tf.shape(updates, out_type='int32')
input_shape = updates.get_shape()
# This statement is required if I don't want to specify a batch size
if input_shape[0] == None:
batches = 1
else:
batches = input_shape[0]
# calculation new shape
if output_shape is None:
output_shape = (
batches,
input_shape[1]*self.size[0],
input_shape[2]*self.size[1],
input_shape[3])
# calculation indices for batch, height, width and feature maps
one_like_mask = tf.ones_like(mask, dtype='int32')
batch_shape = tf.concat(
[[batches], [1], [1], [1]],
axis=0)
batch_range = tf.reshape(
tf.range(output_shape[0], dtype='int32'),
shape=batch_shape)
b = one_like_mask * batch_range
y = mask // (output_shape[2] * output_shape[3])
x = (mask // output_shape[3]) % output_shape[2]
feature_range = tf.range(output_shape[3], dtype='int32')
f = one_like_mask * feature_range
# transpose indices & reshape update values to one dimension
updates_size = tf.size(updates)
indices = tf.transpose(tf.reshape(
tf.stack([b, y, x, f]),
[4, updates_size]))
values = tf.reshape(updates, [updates_size])
ret = tf.scatter_nd(indices, values, output_shape)
return ret
我所担忧的问题有:
- 执行解扁平化指数(MaxUnpooling2D)操作时,严格来说需要知道特定的批次大小,但是对于模型验证,我希望它是无或未指定的。
- 我不确定这段代码是否与整个库实际上完全兼容。实际上,在
fit
期间,如果我使用tf.keras.metrics.MeanIoU
,值会收敛到0.341
,并且在第一个时期之外的每个时期都保持不变。而标准精度指标则运行正常。
深入了解网络架构
接下来是该模型的完整定义。
import tensorflow as tf
import tensorflow.keras as keras
import tensorflow.keras.layers as layers
from tensorflow.keras.layers import Layer
class SegNet:
def __init__(self, data_shape, classes = 3, batch_size = None):
self.MODEL_NAME = 'SegNet'
self.MODEL_VERSION = '0.2'
self.classes = classes
self.batch_size = batch_size
self.build_model(data_shape)
def build_model(self, data_shape):
input_shape = (data_shape, data_shape, 3)
inputs = keras.Input(shape=input_shape, batch_size=self.batch_size, name='Input')
# Build sequential model
# Encoding
encoders = 5
feature_maps = [64, 128, 256, 512, 512]
n_convolutions = [2, 2, 3, 3, 3]
eb_input = inputs
eb_argmax_indices = []
for encoder_index in range(encoders):
encoder_block, argmax_indices = self.encoder_block(
eb_input, encoder_index, feature_maps[encoder_index], n_convolutions[encoder_index])
eb_argmax_indices.append(argmax_indices)
eb_input = encoder_block
# Decoding
decoders = encoders
db_input = encoder_block
eb_argmax_indices.reverse()
feature_maps.reverse()
n_convolutions.reverse()
d_feature_maps = [512, 512, 256, 128, 64]
d_n_convolutions = n_convolutions
for decoder_index in range(decoders):
decoder_block = self.decoder_block(
db_input, eb_argmax_indices[decoder_index], decoder_index, d_feature_maps[decoder_index], d_n_convolutions[decoder_index])
db_input = decoder_block
output = layers.Softmax()(decoder_block)
self.model = keras.Model(inputs=inputs, outputs=output, name="SegNet")
def encoder_block(self, x, encoder_index, feature_maps, n_convolutions):
bank_input = x
for conv_index in range(n_convolutions):
bank = self.eb_layers_bank(
bank_input, conv_index, feature_maps, encoder_index)
bank_input = bank
max_pool, indices = MaxPoolingWithArgmax2D(pool_size=(
2, 2), strides=2, padding='same', name='EB_{}_MPOOL'.format(encoder_index + 1))(bank)
return max_pool, indices
def eb_layers_bank(self, x, bank_index, feature_maps, encoder_index):
bank_input = x
conv_l = layers.Conv2D(feature_maps, (3, 3), padding='same', name='EB_{}_BANK_{}_CONV'.format(
encoder_index + 1, bank_index + 1))(bank_input)
batch_norm = layers.BatchNormalization(
name='EB_{}_BANK_{}_BN'.format(encoder_index + 1, bank_index + 1))(conv_l)
relu = layers.ReLU(name='EB_{}_BANK_{}_RL'.format(
encoder_index + 1, bank_index + 1))(batch_norm)
return relu
def decoder_block(self, x, max_pooling_idices, decoder_index, feature_maps, n_convolutions):
#bank_input = self.unpool_with_argmax(x, max_pooling_idices)
bank_input = MaxUnpooling2D(name='DB_{}_UPSAMP'.format(decoder_index + 1))([x, max_pooling_idices])
#bank_input = layers.UpSampling2D()(x)
for conv_index in range(n_convolutions):
if conv_index == n_convolutions - 1:
last_l_banck = True
else:
last_l_banck = False
bank = self.db_layers_bank(
bank_input, conv_index, feature_maps, decoder_index, last_l_banck)
bank_input = bank
return bank
def db_layers_bank(self, x, bank_index, feature_maps, decoder_index, last_l_bank):
bank_input = x
if (last_l_bank) & (decoder_index == 4):
conv_l = layers.Conv2D(self.classes, (1, 1), padding='same', name='DB_{}_BANK_{}_CONV'.format(
decoder_index + 1, bank_index + 1))(bank_input)
#batch_norm = layers.BatchNormalization(
# name='DB_{}_BANK_{}_BN'.format(decoder_index + 1, bank_index + 1))(conv_l)
return conv_l
else:
if (last_l_bank) & (decoder_index > 0):
conv_l = layers.Conv2D(int(feature_maps / 2), (3, 3), padding='same', name='DB_{}_BANK_{}_CONV'.format(
decoder_index + 1, bank_index + 1))(bank_input)
else:
conv_l = layers.Conv2D(feature_maps, (3, 3), padding='same', name='DB_{}_BANK_{}_CONV'.format(
decoder_index + 1, bank_index + 1))(bank_input)
batch_norm = layers.BatchNormalization(
name='DB_{}_BANK_{}_BN'.format(decoder_index + 1, bank_index + 1))(conv_l)
relu = layers.ReLU(name='DB_{}_BANK_{}_RL'.format(
decoder_index + 1, bank_index + 1))(batch_norm)
return relu
def get_model(self):
return self.model
这里是model.summary()
的输出结果。
Model: "SegNet"
__________________________________________________________________________________________________
Layer (type) Output Shape Param # Connected to
==================================================================================================
Input (InputLayer) [(None, 416, 416, 3) 0
__________________________________________________________________________________________________
EB_1_BANK_1_CONV (Conv2D) (None, 416, 416, 64) 1792 Input[0][0]
__________________________________________________________________________________________________
EB_1_BANK_1_BN (BatchNormalizat (None, 416, 416, 64) 256 EB_1_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
EB_1_BANK_1_RL (ReLU) (None, 416, 416, 64) 0 EB_1_BANK_1_BN[0][0]
__________________________________________________________________________________________________
EB_1_BANK_2_CONV (Conv2D) (None, 416, 416, 64) 36928 EB_1_BANK_1_RL[0][0]
__________________________________________________________________________________________________
EB_1_BANK_2_BN (BatchNormalizat (None, 416, 416, 64) 256 EB_1_BANK_2_CONV[0][0]
__________________________________________________________________________________________________
EB_1_BANK_2_RL (ReLU) (None, 416, 416, 64) 0 EB_1_BANK_2_BN[0][0]
__________________________________________________________________________________________________
EB_1_MPOOL (MaxPoolingWithArgma ((None, 208, 208, 64 0 EB_1_BANK_2_RL[0][0]
__________________________________________________________________________________________________
EB_2_BANK_1_CONV (Conv2D) (None, 208, 208, 128 73856 EB_1_MPOOL[0][0]
__________________________________________________________________________________________________
EB_2_BANK_1_BN (BatchNormalizat (None, 208, 208, 128 512 EB_2_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
EB_2_BANK_1_RL (ReLU) (None, 208, 208, 128 0 EB_2_BANK_1_BN[0][0]
__________________________________________________________________________________________________
EB_2_BANK_2_CONV (Conv2D) (None, 208, 208, 128 147584 EB_2_BANK_1_RL[0][0]
__________________________________________________________________________________________________
EB_2_BANK_2_BN (BatchNormalizat (None, 208, 208, 128 512 EB_2_BANK_2_CONV[0][0]
__________________________________________________________________________________________________
EB_2_BANK_2_RL (ReLU) (None, 208, 208, 128 0 EB_2_BANK_2_BN[0][0]
__________________________________________________________________________________________________
EB_2_MPOOL (MaxPoolingWithArgma ((None, 104, 104, 12 0 EB_2_BANK_2_RL[0][0]
__________________________________________________________________________________________________
EB_3_BANK_1_CONV (Conv2D) (None, 104, 104, 256 295168 EB_2_MPOOL[0][0]
__________________________________________________________________________________________________
EB_3_BANK_1_BN (BatchNormalizat (None, 104, 104, 256 1024 EB_3_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
EB_3_BANK_1_RL (ReLU) (None, 104, 104, 256 0 EB_3_BANK_1_BN[0][0]
__________________________________________________________________________________________________
EB_3_BANK_2_CONV (Conv2D) (None, 104, 104, 256 590080 EB_3_BANK_1_RL[0][0]
__________________________________________________________________________________________________
EB_3_BANK_2_BN (BatchNormalizat (None, 104, 104, 256 1024 EB_3_BANK_2_CONV[0][0]
__________________________________________________________________________________________________
EB_3_BANK_2_RL (ReLU) (None, 104, 104, 256 0 EB_3_BANK_2_BN[0][0]
__________________________________________________________________________________________________
EB_3_BANK_3_CONV (Conv2D) (None, 104, 104, 256 590080 EB_3_BANK_2_RL[0][0]
__________________________________________________________________________________________________
EB_3_BANK_3_BN (BatchNormalizat (None, 104, 104, 256 1024 EB_3_BANK_3_CONV[0][0]
__________________________________________________________________________________________________
EB_3_BANK_3_RL (ReLU) (None, 104, 104, 256 0 EB_3_BANK_3_BN[0][0]
__________________________________________________________________________________________________
EB_3_MPOOL (MaxPoolingWithArgma ((None, 52, 52, 256) 0 EB_3_BANK_3_RL[0][0]
__________________________________________________________________________________________________
EB_4_BANK_1_CONV (Conv2D) (None, 52, 52, 512) 1180160 EB_3_MPOOL[0][0]
__________________________________________________________________________________________________
EB_4_BANK_1_BN (BatchNormalizat (None, 52, 52, 512) 2048 EB_4_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
EB_4_BANK_1_RL (ReLU) (None, 52, 52, 512) 0 EB_4_BANK_1_BN[0][0]
__________________________________________________________________________________________________
EB_4_BANK_2_CONV (Conv2D) (None, 52, 52, 512) 2359808 EB_4_BANK_1_RL[0][0]
__________________________________________________________________________________________________
EB_4_BANK_2_BN (BatchNormalizat (None, 52, 52, 512) 2048 EB_4_BANK_2_CONV[0][0]
__________________________________________________________________________________________________
EB_4_BANK_2_RL (ReLU) (None, 52, 52, 512) 0 EB_4_BANK_2_BN[0][0]
__________________________________________________________________________________________________
EB_4_BANK_3_CONV (Conv2D) (None, 52, 52, 512) 2359808 EB_4_BANK_2_RL[0][0]
__________________________________________________________________________________________________
EB_4_BANK_3_BN (BatchNormalizat (None, 52, 52, 512) 2048 EB_4_BANK_3_CONV[0][0]
__________________________________________________________________________________________________
EB_4_BANK_3_RL (ReLU) (None, 52, 52, 512) 0 EB_4_BANK_3_BN[0][0]
__________________________________________________________________________________________________
EB_4_MPOOL (MaxPoolingWithArgma ((None, 26, 26, 512) 0 EB_4_BANK_3_RL[0][0]
__________________________________________________________________________________________________
EB_5_BANK_1_CONV (Conv2D) (None, 26, 26, 512) 2359808 EB_4_MPOOL[0][0]
__________________________________________________________________________________________________
EB_5_BANK_1_BN (BatchNormalizat (None, 26, 26, 512) 2048 EB_5_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
EB_5_BANK_1_RL (ReLU) (None, 26, 26, 512) 0 EB_5_BANK_1_BN[0][0]
__________________________________________________________________________________________________
EB_5_BANK_2_CONV (Conv2D) (None, 26, 26, 512) 2359808 EB_5_BANK_1_RL[0][0]
__________________________________________________________________________________________________
EB_5_BANK_2_BN (BatchNormalizat (None, 26, 26, 512) 2048 EB_5_BANK_2_CONV[0][0]
__________________________________________________________________________________________________
EB_5_BANK_2_RL (ReLU) (None, 26, 26, 512) 0 EB_5_BANK_2_BN[0][0]
__________________________________________________________________________________________________
EB_5_BANK_3_CONV (Conv2D) (None, 26, 26, 512) 2359808 EB_5_BANK_2_RL[0][0]
__________________________________________________________________________________________________
EB_5_BANK_3_BN (BatchNormalizat (None, 26, 26, 512) 2048 EB_5_BANK_3_CONV[0][0]
__________________________________________________________________________________________________
EB_5_BANK_3_RL (ReLU) (None, 26, 26, 512) 0 EB_5_BANK_3_BN[0][0]
__________________________________________________________________________________________________
EB_5_MPOOL (MaxPoolingWithArgma ((None, 13, 13, 512) 0 EB_5_BANK_3_RL[0][0]
__________________________________________________________________________________________________
DB_1_UPSAMP (MaxUnpooling2D) (1, 26, 26, 512) 0 EB_5_MPOOL[0][0]
EB_5_MPOOL[0][1]
__________________________________________________________________________________________________
DB_1_BANK_1_CONV (Conv2D) (1, 26, 26, 512) 2359808 DB_1_UPSAMP[0][0]
__________________________________________________________________________________________________
DB_1_BANK_1_BN (BatchNormalizat (1, 26, 26, 512) 2048 DB_1_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
DB_1_BANK_1_RL (ReLU) (1, 26, 26, 512) 0 DB_1_BANK_1_BN[0][0]
__________________________________________________________________________________________________
DB_1_BANK_2_CONV (Conv2D) (1, 26, 26, 512) 2359808 DB_1_BANK_1_RL[0][0]
__________________________________________________________________________________________________
DB_1_BANK_2_BN (BatchNormalizat (1, 26, 26, 512) 2048 DB_1_BANK_2_CONV[0][0]
__________________________________________________________________________________________________
DB_1_BANK_2_RL (ReLU) (1, 26, 26, 512) 0 DB_1_BANK_2_BN[0][0]
__________________________________________________________________________________________________
DB_1_BANK_3_CONV (Conv2D) (1, 26, 26, 512) 2359808 DB_1_BANK_2_RL[0][0]
__________________________________________________________________________________________________
DB_1_BANK_3_BN (BatchNormalizat (1, 26, 26, 512) 2048 DB_1_BANK_3_CONV[0][0]
__________________________________________________________________________________________________
DB_1_BANK_3_RL (ReLU) (1, 26, 26, 512) 0 DB_1_BANK_3_BN[0][0]
__________________________________________________________________________________________________
DB_2_UPSAMP (MaxUnpooling2D) (1, 52, 52, 512) 0 DB_1_BANK_3_RL[0][0]
EB_4_MPOOL[0][1]
__________________________________________________________________________________________________
DB_2_BANK_1_CONV (Conv2D) (1, 52, 52, 512) 2359808 DB_2_UPSAMP[0][0]
__________________________________________________________________________________________________
DB_2_BANK_1_BN (BatchNormalizat (1, 52, 52, 512) 2048 DB_2_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
DB_2_BANK_1_RL (ReLU) (1, 52, 52, 512) 0 DB_2_BANK_1_BN[0][0]
__________________________________________________________________________________________________
DB_2_BANK_2_CONV (Conv2D) (1, 52, 52, 512) 2359808 DB_2_BANK_1_RL[0][0]
__________________________________________________________________________________________________
DB_2_BANK_2_BN (BatchNormalizat (1, 52, 52, 512) 2048 DB_2_BANK_2_CONV[0][0]
__________________________________________________________________________________________________
DB_2_BANK_2_RL (ReLU) (1, 52, 52, 512) 0 DB_2_BANK_2_BN[0][0]
__________________________________________________________________________________________________
DB_2_BANK_3_CONV (Conv2D) (1, 52, 52, 256) 1179904 DB_2_BANK_2_RL[0][0]
__________________________________________________________________________________________________
DB_2_BANK_3_BN (BatchNormalizat (1, 52, 52, 256) 1024 DB_2_BANK_3_CONV[0][0]
__________________________________________________________________________________________________
DB_2_BANK_3_RL (ReLU) (1, 52, 52, 256) 0 DB_2_BANK_3_BN[0][0]
__________________________________________________________________________________________________
DB_3_UPSAMP (MaxUnpooling2D) (1, 104, 104, 256) 0 DB_2_BANK_3_RL[0][0]
EB_3_MPOOL[0][1]
__________________________________________________________________________________________________
DB_3_BANK_1_CONV (Conv2D) (1, 104, 104, 256) 590080 DB_3_UPSAMP[0][0]
__________________________________________________________________________________________________
DB_3_BANK_1_BN (BatchNormalizat (1, 104, 104, 256) 1024 DB_3_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
DB_3_BANK_1_RL (ReLU) (1, 104, 104, 256) 0 DB_3_BANK_1_BN[0][0]
__________________________________________________________________________________________________
DB_3_BANK_2_CONV (Conv2D) (1, 104, 104, 256) 590080 DB_3_BANK_1_RL[0][0]
__________________________________________________________________________________________________
DB_3_BANK_2_BN (BatchNormalizat (1, 104, 104, 256) 1024 DB_3_BANK_2_CONV[0][0]
__________________________________________________________________________________________________
DB_3_BANK_2_RL (ReLU) (1, 104, 104, 256) 0 DB_3_BANK_2_BN[0][0]
__________________________________________________________________________________________________
DB_3_BANK_3_CONV (Conv2D) (1, 104, 104, 128) 295040 DB_3_BANK_2_RL[0][0]
__________________________________________________________________________________________________
DB_3_BANK_3_BN (BatchNormalizat (1, 104, 104, 128) 512 DB_3_BANK_3_CONV[0][0]
__________________________________________________________________________________________________
DB_3_BANK_3_RL (ReLU) (1, 104, 104, 128) 0 DB_3_BANK_3_BN[0][0]
__________________________________________________________________________________________________
DB_4_UPSAMP (MaxUnpooling2D) (1, 208, 208, 128) 0 DB_3_BANK_3_RL[0][0]
EB_2_MPOOL[0][1]
__________________________________________________________________________________________________
DB_4_BANK_1_CONV (Conv2D) (1, 208, 208, 128) 147584 DB_4_UPSAMP[0][0]
__________________________________________________________________________________________________
DB_4_BANK_1_BN (BatchNormalizat (1, 208, 208, 128) 512 DB_4_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
DB_4_BANK_1_RL (ReLU) (1, 208, 208, 128) 0 DB_4_BANK_1_BN[0][0]
__________________________________________________________________________________________________
DB_4_BANK_2_CONV (Conv2D) (1, 208, 208, 64) 73792 DB_4_BANK_1_RL[0][0]
__________________________________________________________________________________________________
DB_4_BANK_2_BN (BatchNormalizat (1, 208, 208, 64) 256 DB_4_BANK_2_CONV[0][0]
__________________________________________________________________________________________________
DB_4_BANK_2_RL (ReLU) (1, 208, 208, 64) 0 DB_4_BANK_2_BN[0][0]
__________________________________________________________________________________________________
DB_5_UPSAMP (MaxUnpooling2D) (1, 416, 416, 64) 0 DB_4_BANK_2_RL[0][0]
EB_1_MPOOL[0][1]
__________________________________________________________________________________________________
DB_5_BANK_1_CONV (Conv2D) (1, 416, 416, 64) 36928 DB_5_UPSAMP[0][0]
__________________________________________________________________________________________________
DB_5_BANK_1_BN (BatchNormalizat (1, 416, 416, 64) 256 DB_5_BANK_1_CONV[0][0]
__________________________________________________________________________________________________
DB_5_BANK_1_RL (ReLU) (1, 416, 416, 64) 0 DB_5_BANK_1_BN[0][0]
__________________________________________________________________________________________________
DB_5_BANK_2_CONV (Conv2D) (1, 416, 416, 3) 195 DB_5_BANK_1_RL[0][0]
__________________________________________________________________________________________________
softmax (Softmax) (1, 416, 416, 3) 0 DB_5_BANK_2_CONV[0][0]
==================================================================================================
Total params: 29,459,075
Trainable params: 29,443,203
Non-trainable params: 15,872
__________________________________________________________________________________________________
如您所见,在MaxUnpooling2D中我被迫指定一个批处理大小,否则会出现错误,因为存在None
值且形状无法正确转换。
当我尝试预测一张图片时,我必须指定正确的批处理维度,否则会出现如下错误:
InvalidArgumentError: Shapes of all inputs must match: values[0].shape = [4,208,208,64] != values[1].shape = [1,208,208,64]
[[{{node SegNet/DB_5_UPSAMP/PartitionedCall/PartitionedCall/DB_5_UPSAMP/stack}}]] [Op:__inference_predict_function_70839]
这是由实现要求引起的,目的是为了解开最大池化操作中的索引。
训练图表
这里是一个训练20个epochs的参考。
如您所见,MeanIoU指标是线性的,没有进展,除了第1个epoch之外没有更新。
另一个指标正常工作,损失正确降低。
––––––––––
结论
- 有没有更好的方法来实现从最大池化操作中的索引解开和上采样,以便与TF的最新版本更兼容?
- 如果实现正确,为什么我的指标被卡在特定值?我在模型中做错了什么吗?
谢谢!
