如何在Keras层内使用SVD？

Question

我的目标是在将潜在层传递给自编码器的解码器模块之前，使用SVD对PCA进行白化处理。我已经使用了tf.linalg.svd，但它不起作用，因为它不包含必要的Keras参数。因此，我尝试将其包装在Lambda中，但出现了以下错误

AttributeError: 'tuple' object has no attribute 'shape'

我尝试了SO（例如在Keras / tensorflow中的自定义层中使用SVD），并在Google中搜索了SVD在Keras中的相关问题，但没有找到任何答案。我在这里附上了一个简化但功能齐全的代码：

import numpy as np
import tensorflow as tf
from sklearn import preprocessing
from keras.layers import Lambda, Input, Dense, Multiply, Subtract
from keras.models import Model
from keras import backend as K
from keras.losses import mse
from keras import optimizers
from keras.callbacks import EarlyStopping

x = np.random.randn(100, 5)
train_data = preprocessing.scale(x)

input_shape = (5, )
original_dim = train_data.shape[1]
intermediate_dim_1 = 64
intermediate_dim_2 = 16
latent_dim = 2
batch_size = 10
epochs = 15


# build encoder model
inputs = Input(shape=input_shape, name='encoder_input')
layer_1 = Dense(intermediate_dim_1, activation='tanh') (inputs)
layer_2 = Dense(intermediate_dim_2, activation='tanh') (layer_1)
encoded_layer = Dense(latent_dim, name='latent_layer') (layer_2)
encoder = Model(inputs, encoded_layer, name='encoder')
encoder.summary()


# build decoder model
latent_inputs = Input(shape=(latent_dim,))
layer_1 = Dense(intermediate_dim_1, activation='tanh') (latent_inputs)
layer_2 = Dense(intermediate_dim_2, activation='tanh') (layer_1)
outputs = Dense(original_dim,activation='sigmoid') (layer_2)
decoder = Model(latent_inputs, outputs, name='decoder')
decoder.summary()

# mean removal and pca whitening
meanX = Lambda(lambda x: tf.reduce_mean(x, axis=0, keepdims=True))(encoded_layer)
standardized = Subtract()([encoded_layer, meanX])

sigma2 = K.dot(K.transpose(standardized), standardized)
sigma2 = Lambda(lambda x: x / batch_size)(sigma2)


s, u ,v = tf.linalg.svd(sigma2,compute_uv=True)
# s ,u ,v = Lambda(lambda x: tf.linalg.svd(x,compute_uv=True))(sigma2)

epsilon = 1e-6
# sqrt of number close to 0 leads to problem hence replace it with epsilon
si = tf.where(tf.less(s, epsilon), tf.sqrt(1 / epsilon) * tf.ones_like(s),
              tf.math.truediv(1.0, tf.sqrt(s)))
whitening_layer = u @ tf.linalg.diag(si) @ tf.transpose(v)
whitened_encoding = K.dot(standardized, whitening_layer)

# Connect models
z_decoded = decoder(standardized)
# z_decoded = decoder(whitened_encoding)

# Define losses
reconstruction_loss = mse(inputs,z_decoded)

# Instantiate autoencoder
ae = Model(inputs, z_decoded, name='autoencoder')
ae.add_loss(reconstruction_loss)

# callback = EarlyStopping(monitor='val_loss', patience=5)
adam = optimizers.adam(learning_rate=0.002)
ae.compile(optimizer=adam)
ae.summary()
ae.fit(train_data, epochs=epochs, batch_size=batch_size,
       validation_split=0.2, shuffle=True)

要重现错误，请取消注释这些行并注释其前面的行：

1. z_decoded = decoder(whitened_encoding)

2. s，u，v = Lambda(lambda x：tf.linalg.svd（x，compute_uv = True）)(sigma2)

如果有人能告诉我如何在Keras层中包装SVD或备用实现，我将不胜感激。 请注意，为了保持代码简单，我没有包括重新参数化技巧来计算损失。 谢谢！

- Manish

Answer 1

我解决了这个问题。在Keras中使用SVD，我们需要使用Lambda层。但是，由于Lambda返回带有一些附加属性的张量，最好在lambda函数内部进行额外的工作并返回一个张量。我的代码另一个问题是编码器和解码器模型的组合，我通过将编码器的输出与解码器模型的输入相结合来解决了这个问题。工作代码如下：

import numpy as np
import tensorflow as tf
from sklearn import preprocessing
from keras.layers import Lambda, Input, Dense, Multiply, Subtract
from keras.models import Model
from keras import backend as K
from keras.losses import mse
from keras import optimizers
from keras.callbacks import EarlyStopping

def SVD(sigma2):
    s ,u ,v = tf.linalg.svd(sigma2,compute_uv=True)
    epsilon = 1e-6
    # sqrt of number close to 0 leads to problem hence replace it with epsilon
    si = tf.where(tf.less(s, epsilon),
                  tf.sqrt(1 / epsilon) * tf.ones_like(s),
                  tf.math.truediv(1.0, tf.sqrt(s)))
    whitening_layer = u @ tf.linalg.diag(si) @ tf.transpose(v)
    return whitening_layer

x = np.random.randn(100, 5)
train_data = preprocessing.scale(x)

input_shape = (5, )
original_dim = train_data.shape[1]
intermediate_dim_1 = 64
intermediate_dim_2 = 16
latent_dim = 2
batch_size = 10
epochs = 15


# build encoder model
inputs = Input(shape=input_shape, name='encoder_input')
layer_1 = Dense(intermediate_dim_1, activation='tanh') (inputs)
layer_2 = Dense(intermediate_dim_2, activation='tanh') (layer_1)
encoded_layer = Dense(latent_dim, name='latent_layer') (layer_2)
encoder = Model(inputs, encoded_layer, name='encoder')
encoder.summary()


# build decoder model
latent_inputs = Input(shape=(latent_dim,))
layer_1 = Dense(intermediate_dim_1, activation='tanh') (latent_inputs)
layer_2 = Dense(intermediate_dim_2, activation='tanh') (layer_1)
outputs = Dense(original_dim,activation='sigmoid') (layer_2)
decoder = Model(latent_inputs, outputs, name='decoder')
decoder.summary()

# mean removal and pca whitening
meanX = Lambda(lambda x: tf.reduce_mean(x, axis=0, keepdims=True))(encoded_layer)
standardized = Subtract()([encoded_layer, meanX])

sigma2 = K.dot(K.transpose(standardized), standardized)
sigma2 = Lambda(lambda x: x / batch_size)(sigma2)


# s, u ,v = tf.linalg.svd(sigma2,compute_uv=True)
whitening_layer = Lambda(SVD)(sigma2)
'''
s ,u ,v = Lambda(lambda x: tf.linalg.svd(x,compute_uv=True))(sigma2)

epsilon = 1e-6
# sqrt of number close to 0 leads to problem hence replace it with epsilon
si = tf.where(tf.less(s, epsilon),
              tf.sqrt(1 / epsilon) * tf.ones_like(s),
              tf.math.truediv(1.0, tf.sqrt(s)))
whitening_layer = u @ tf.linalg.diag(si) @ tf.transpose(v)
'''

print('whitening_layer shape=', np.shape(whitening_layer))
print('standardized shape=', np.shape(standardized))

whitened_encoding = K.dot(standardized, whitening_layer)

# Connect models
# z_decoded = decoder(standardized)
z_decoded = decoder(encoder(inputs))

# Define losses
reconstruction_loss = mse(inputs,z_decoded)

# Instantiate autoencoder
ae = Model(inputs, z_decoded, name='autoencoder')
ae.add_loss(reconstruction_loss)

# callback = EarlyStopping(monitor='val_loss', patience=5)
adam = optimizers.adam(learning_rate=0.002)
ae.compile(optimizer=adam)
ae.summary()
ae.fit(train_data, epochs=epochs, batch_size=batch_size,
       validation_split=0.2, shuffle=True)

运行代码的输出如下：

    Model: "encoder"
_________________________________________________________________
Layer (type)                 Output Shape              Param #
=================================================================
encoder_input (InputLayer)   (None, 5)                 0
_________________________________________________________________
dense_1 (Dense)              (None, 64)                384
_________________________________________________________________
dense_2 (Dense)              (None, 16)                1040
_________________________________________________________________
latent_layer (Dense)         (None, 2)                 34
=================================================================
Total params: 1,458
Trainable params: 1,458
Non-trainable params: 0
_________________________________________________________________
Model: "decoder"
_________________________________________________________________
Layer (type)                 Output Shape              Param #
=================================================================
input_1 (InputLayer)         (None, 2)                 0
_________________________________________________________________
dense_3 (Dense)              (None, 64)                192
_________________________________________________________________
dense_4 (Dense)              (None, 16)                1040
_________________________________________________________________
dense_5 (Dense)              (None, 5)                 85
=================================================================
Total params: 1,317
Trainable params: 1,317
Non-trainable params: 0
_________________________________________________________________
whitening_layer shape= (2, 2)
standardized shape= (None, 2)
/home/manish/anaconda3/envs/ica_gpu/lib/python3.7/site-packages/keras/engine/training_utils.py:819: UserWarning: Output decoder missing from loss dictionary. We assume this was done on purpose. The fit and evaluate APIs will not be expecting any data to be passed to decoder.
  'be expecting any data to be passed to {0}.'.format(name))
Model: "autoencoder"
_________________________________________________________________
Layer (type)                 Output Shape              Param #
=================================================================
encoder_input (InputLayer)   (None, 5)                 0
_________________________________________________________________
encoder (Model)              (None, 2)                 1458
_________________________________________________________________
decoder (Model)              (None, 5)                 1317
=================================================================
Total params: 2,775
Trainable params: 2,775
Non-trainable params: 0
_________________________________________________________________
Train on 80 samples, validate on 20 samples
Epoch 1/15
2020-05-16 16:01:55.443061: I tensorflow/stream_executor/platform/default/dso_loader.cc:44] Successfully opened dynamic library libcublas.so.10
80/80 [==============================] - 0s 3ms/step - loss: 1.1739 - val_loss: 1.2238
Epoch 2/15
80/80 [==============================] - 0s 228us/step - loss: 1.0601 - val_loss: 1.0921
Epoch 3/15
80/80 [==============================] - 0s 261us/step - loss: 0.9772 - val_loss: 1.0291
Epoch 4/15
80/80 [==============================] - 0s 223us/step - loss: 0.9385 - val_loss: 0.9875
Epoch 5/15
80/80 [==============================] - 0s 262us/step - loss: 0.9105 - val_loss: 0.9560
Epoch 6/15
80/80 [==============================] - 0s 240us/step - loss: 0.8873 - val_loss: 0.9335
Epoch 7/15
80/80 [==============================] - 0s 217us/step - loss: 0.8731 - val_loss: 0.9156
Epoch 8/15
80/80 [==============================] - 0s 253us/step - loss: 0.8564 - val_loss: 0.9061
Epoch 9/15
80/80 [==============================] - 0s 273us/step - loss: 0.8445 - val_loss: 0.8993
Epoch 10/15
80/80 [==============================] - 0s 235us/step - loss: 0.8363 - val_loss: 0.8937
Epoch 11/15
80/80 [==============================] - 0s 283us/step - loss: 0.8299 - val_loss: 0.8874
Epoch 12/15
80/80 [==============================] - 0s 254us/step - loss: 0.8227 - val_loss: 0.8832
Epoch 13/15
80/80 [==============================] - 0s 227us/step - loss: 0.8177 - val_loss: 0.8789
Epoch 14/15
80/80 [==============================] - 0s 241us/step - loss: 0.8142 - val_loss: 0.8725
Epoch 15/15
80/80 [==============================] - 0s 212us/step - loss: 0.8089 - val_loss: 0.8679

我希望这能有所帮助。

- Manish
