Spark SQL + Cassandra：性能差

Question

Spark SQL + Cassandra：性能差

scalacassandraapache-spark-sqlspark-cassandra-connector

5

我刚刚开始使用Spark SQL + Cassandra，可能缺少重要的东西，但一个简单的查询需要大约45秒。我使用cassandra-spark-connector库，并运行本地Web服务器，该服务器还托管Spark。因此，我的设置大致如下：

在sbt中：

    "org.apache.spark" %% "spark-core" % "1.4.1" excludeAll(ExclusionRule(organization = "org.slf4j")),
    "org.apache.spark" %% "spark-sql" % "1.4.1" excludeAll(ExclusionRule(organization = "org.slf4j")),
    "com.datastax.spark" %% "spark-cassandra-connector" % "1.4.0-M3" excludeAll(ExclusionRule(organization = "org.slf4j"))

我有一个单例对象，其中包含SparkContext和CassandraSQLContetx。然后从servlet中调用它。下面是单例对象的代码：

object SparkModel {

  val conf =
    new SparkConf()
      .setAppName("core")
      .setMaster("local")
      .set("spark.cassandra.connection.host", "127.0.0.1")

  val sc = new SparkContext(conf)
  val sqlC = new CassandraSQLContext(sc)
  sqlC.setKeyspace("core")

  val df: DataFrame = sqlC.cassandraSql(
    "SELECT email, target_entity_id, target_entity_type " +
    "FROM tracking_events " +
    "LEFT JOIN customers " +
    "WHERE entity_type = 'User' AND entity_id = customer_id")
}

以下是我如何使用它：

get("/spark") {
  SparkModel.df.collect().map(r => TrackingEvent(r.getString(0), r.getString(1), r.getString(2))).toList
}

在我的Macbook Pro电脑上，Cassandra、Spark和Web应用程序在虚拟机中运行。Cassandra查询本身需要10-20毫秒。

当我第一次调用此端点时，返回结果需要70-80秒。后续查询需要约45秒左右。其日志如下所示：

12:48:50 INFO  org.apache.spark.SparkContext - Starting job: collect at V1Servlet.scala:1146
12:48:50 INFO  o.a.spark.scheduler.DAGScheduler - Got job 1 (collect at V1Servlet.scala:1146) with 1 output partitions (allowLocal=false)
12:48:50 INFO  o.a.spark.scheduler.DAGScheduler - Final stage: ResultStage 1(collect at V1Servlet.scala:1146)
12:48:50 INFO  o.a.spark.scheduler.DAGScheduler - Parents of final stage: List()
12:48:50 INFO  o.a.spark.scheduler.DAGScheduler - Missing parents: List()
12:48:50 INFO  o.a.spark.scheduler.DAGScheduler - Submitting ResultStage 1 (MapPartitionsRDD[29] at collect at V1Servlet.scala:1146), which has no missing parents
12:48:50 INFO  org.apache.spark.storage.MemoryStore - ensureFreeSpace(18696) called with curMem=26661, maxMem=825564856
12:48:50 INFO  org.apache.spark.storage.MemoryStore - Block broadcast_1 stored as values in memory (estimated size 18.3 KB, free 787.3 MB)
12:48:50 INFO  org.apache.spark.storage.MemoryStore - ensureFreeSpace(8345) called with curMem=45357, maxMem=825564856
12:48:50 INFO  org.apache.spark.storage.MemoryStore - Block broadcast_1_piece0 stored as bytes in memory (estimated size 8.1 KB, free 787.3 MB)
12:48:50 INFO  o.a.spark.storage.BlockManagerInfo - Added broadcast_1_piece0 in memory on localhost:56289 (size: 8.1 KB, free: 787.3 MB)
12:48:50 INFO  org.apache.spark.SparkContext - Created broadcast 1 from broadcast at DAGScheduler.scala:874
12:48:50 INFO  o.a.spark.scheduler.DAGScheduler - Submitting 1 missing tasks from ResultStage 1 (MapPartitionsRDD[29] at collect at V1Servlet.scala:1146)
12:48:50 INFO  o.a.s.scheduler.TaskSchedulerImpl - Adding task set 1.0 with 1 tasks
12:48:50 INFO  o.a.spark.scheduler.TaskSetManager - Starting task 0.0 in stage 1.0 (TID 1, localhost, NODE_LOCAL, 59413 bytes)
12:48:50 INFO  org.apache.spark.executor.Executor - Running task 0.0 in stage 1.0 (TID 1)
12:48:50 INFO  com.datastax.driver.core.Cluster - New Cassandra host localhost/127.0.0.1:9042 added
12:48:50 INFO  c.d.s.c.cql.CassandraConnector - Connected to Cassandra cluster: Super Cluster
12:49:11 INFO  o.a.spark.storage.BlockManagerInfo - Removed broadcast_0_piece0 on localhost:56289 in memory (size: 8.0 KB, free: 787.3 MB)
12:49:35 INFO  org.apache.spark.executor.Executor - Finished task 0.0 in stage 1.0 (TID 1). 6124 bytes result sent to driver
12:49:35 INFO  o.a.spark.scheduler.TaskSetManager - Finished task 0.0 in stage 1.0 (TID 1) in 45199 ms on localhost (1/1)
12:49:35 INFO  o.a.s.scheduler.TaskSchedulerImpl - Removed TaskSet 1.0, whose tasks have all completed, from pool
12:49:35 INFO  o.a.spark.scheduler.DAGScheduler - ResultStage 1 (collect at V1Servlet.scala:1146) finished in 45.199 s

从日志中可以看出，最长的停顿时间出现在这三行之间（21+24秒）：

12:48:50 INFO  c.d.s.c.cql.CassandraConnector - Connected to Cassandra cluster: Super Cluster
12:49:11 INFO  o.a.spark.storage.BlockManagerInfo - Removed broadcast_0_piece0 on localhost:56289 in memory (size: 8.0 KB, free: 787.3 MB)
12:49:35 INFO  org.apache.spark.executor.Executor - Finished task 0.0 in stage 1.0 (TID 1). 6124 bytes result sent to driver

显然，我做错了些什么。是什么呢？我该如何改进呢？

编辑：重要补充：表的大小很小（tracking_events 大约有200条条目，customers 大约有20条），因此将它们全部读入内存不应花费任何明显时间。而且这是一个本地Cassandra安装，没有集群，不涉及网络。

- Haspemulator

1个回答

网页内容由stack overflow 提供, 点击上面的

可以查看英文原文，
原文链接

- RussS · Accepted Answer

  "SELECT email, target_entity_id, target_entity_type " +
    "FROM tracking_events " +
    "LEFT JOIN customers " +
    "WHERE entity_type = 'User' AND entity_id = customer_id")

这个查询将读取tracking_events和customers两个表中的所有数据。我会将其与仅在两个表上执行SELECT COUNT(*)的性能进行比较。如果差异显著，则可能存在问题，但我猜测这只是完全读取两个表所需的时间。

有一些用于调整读取方式的旋钮，由于默认值面向更大的数据集，因此您可能需要更改这些值。

spark.cassandra.input.split.size_in_mb  approx amount of data to be fetched into a Spark partition  64 MB
spark.cassandra.input.fetch.size_in_rows    number of CQL rows fetched per driver request   1000

我会确保生成与核心数量相同（至少）的任务，以便利用所有资源。为此，请缩小输入分割大小。

提取大小控制执行器内核一次分页的行数，因此在某些使用情况下增加它可以提高速度。
