Arstechnia最近发表了一篇文章《为什么有些编程语言比其他编程语言更快》,比较了Fortran和C,并提到了数组求和。在Fortran中,假定数组不重叠,因此可以进一步优化。在C/C++中,类型相同的指针可能会重叠,因此通常无法使用此优化。但是,在C/C++中,可以使用
以下代码能在GCC和MSVC中进行向量化。
restrict
或__restrict
关键字告诉编译器不要假定指针重叠。因此我开始研究这个问题与自动向量化相关的内容。以下代码能在GCC和MSVC中进行向量化。
void dot_int(int *a, int *b, int *c, int n) {
for(int i=0; i<n; i++) {
c[i] = a[i] + b[i];
}
}
我测试了包含和不包含重叠数组的情况,并且得到了正确的结果。然而,如果我手动使用SSE向量化这个循环的方式不能处理重叠的数组。
int i=0;
for(; i<n-3; i+=4) {
__m128i a4 = _mm_loadu_si128((__m128i*)&a[i]);
__m128i b4 = _mm_loadu_si128((__m128i*)&b[i]);
__m128i c4 = _mm_add_epi32(a4,b4);
_mm_storeu_si128((__m128i*)c, c4);
}
for(; i<n; i++) {
c[i] = a[i] + b[i];
}
接下来我尝试使用__restrict
。我认为由于编译器可以假设数组不重叠,因此它不会处理重叠的数组,但无论是GCC还是MSVC都可以在使用__restrict
时得到正确的结果,即使数组重叠。
void dot_int_restrict(int * __restrict a, int * __restrict b, int * __restrict c, int n) {
for(int i=0; i<n; i++) {
c[i] = a[i] + b[i];
}
}
为什么使用和不使用__restrict
的自动向量化代码可以正确处理重叠数组?
以下是我用来测试的完整代码:
#include <stdio.h>
#include <immintrin.h>
void dot_int(int *a, int *b, int *c, int n) {
for(int i=0; i<n; i++) {
c[i] = a[i] + b[i];
}
for(int i=0; i<8; i++) printf("%d ", c[i]); printf("\n");
}
void dot_int_restrict(int * __restrict a, int * __restrict b, int * __restrict c, int n) {
for(int i=0; i<n; i++) {
c[i] = a[i] + b[i];
}
for(int i=0; i<8; i++) printf("%d ", c[i]); printf("\n");
}
void dot_int_SSE(int *a, int *b, int *c, int n) {
int i=0;
for(; i<n-3; i+=4) {
__m128i a4 = _mm_loadu_si128((__m128i*)&a[i]);
__m128i b4 = _mm_loadu_si128((__m128i*)&b[i]);
__m128i c4 = _mm_add_epi32(a4,b4);
_mm_storeu_si128((__m128i*)c, c4);
}
for(; i<n; i++) {
c[i] = a[i] + b[i];
}
for(int i=0; i<8; i++) printf("%d ", c[i]); printf("\n");
}
int main() {
const int n = 100;
int a[] = {1,1,1,1,1,1,1,1};
int b1[] = {1,1,1,1,1,1,1,1,1};
int b2[] = {1,1,1,1,1,1,1,1,1};
int b3[] = {1,1,1,1,1,1,1,1,1};
int c[8];
int *c1 = &b1[1];
int *c2 = &b2[1];
int *c3 = &b3[1];
dot_int(a,b1,c, 8);
dot_int_SSE(a,b1,c,8);
dot_int(a,b1,c1, 8);
dot_int_restrict(a,b2,c2,8);
dot_int_SSE(a,b3,c3,8);
}
输出结果(来自 MSVC)
2 2 2 2 2 2 2 2 //no overlap default
2 2 2 2 2 2 2 2 //no overlap with manual SSE vector code
2 3 4 5 6 7 8 9 //overlap default
2 3 4 5 6 7 8 9 //overlap with restrict
3 2 2 2 1 1 1 1 //manual SSE vector code
编辑:
这里还有一个更简单的版本,它生成的代码非常简洁。
void dot_int(int * __restrict a, int * __restrict b, int * __restrict c, int n) {
a = (int*)__builtin_assume_aligned (a, 16);
b = (int*)__builtin_assume_aligned (b, 16);
c = (int*)__builtin_assume_aligned (c, 16);
for(int i=0; i<n; i++) {
c[i] = a[i] + b[i];
}
}
c
数组与输入的b
数组重叠。手动SSE代码失败的原因是因为加载存储顺序很重要。 - Z boson
