显而易见。我想,如果您正在阅读此内容,则应该知道如何操作。
否则,您可以前往此处的文档查看:什么是AWS Step Functions?.
它可以用于所有步骤函数,也可以只用于此步骤函数。我们只会涵盖第一种情况,如Amazon教程中所述:使用API Gateway创建API.
创建IAM角色
登录到AWS身份和访问管理控制台。
在角色页面上,选择“创建新角色”。
在设置角色名称页面上,输入Role Name为APIGatewayToStepFunctions,然后选择下一步。
在选择角色类型页面上,在选择角色类型下,选择Amazon API Gateway。
在附加策略页面上,选择下一步。
在审核页面上,注意Role ARN,例如:
arn:aws:iam::123456789012:role/APIGatewayToStepFunctions
- 选择创建角色。
将策略附加到IAM角色
- 在角色页面上,按名称(APIGatewayToStepFunctions)搜索角色,然后选择该角色。
- 在权限选项卡上,选择“附加策略”。
- 在附加策略页面上,搜索AWSStepFunctionsFullAccess,选择策略,然后选择“附加策略”。
如Ka Hou Ieong在如何通过API Gateway调用AWS Step Functions?中所述,您可以通过API Gateway控制台创建AWS Service集成,如下所示:
标头:
X-Amz-Target -> 'AWSStepFunctions.StartExecution'
Content-Type -> 'application/x-amz-json-1.0'
Body Mapping Templates/Request payload:
{
"input": "string" (optional),
"name": "string" (optional),
"stateMachineArn": "string"
}
一切都与2.a相同,除了请求体映射模板。您需要将其转换为字符串。例如使用$util.escapeJavascript()。它将整个请求体作为输入传递给您的步骤函数。
#set($data = $util.escapeJavaScript($input.json('$')))
{
"input": "$data",
"name": "string" (optional),
"stateMachineArn": "string" (required)
}
stateMachineArn
: 如果您不想将 stateMachineArn 作为请求 API Gateway 的一部分传递,可以在您的 Body Mapping 模板内将其硬编码(参见 AWS API Gateway with Step Function)name
: 省略 name 属性将导致 API Gateway 在每次执行时为您生成不同的名称。这是我的第一个“自问自答”,所以可能这不是正确的方式,但我花了相当多的时间来尝试理解我的 Mapping Template 出了什么问题。希望这能帮助节省其他人的时间和精力。
对于那些想要使用OpenApi集成和CloudFormation直接连接 ApiGateway 和Step Functions State Machine的人,这是我成功实现它的示例:
这是我设计的可视化工作流程(有关详细信息,请参见CloudFormation文件)作为概念验证:
template.yaml
AWSTemplateFormatVersion: 2010-09-09
Transform: 'AWS::Serverless-2016-10-31'
Description: POC Lambda Examples - Step Functions
Parameters:
CorsOrigin:
Description: Header Access-Control-Allow-Origin
Default: "'http://localhost:3000'"
Type: String
CorsMethods:
Description: Header Access-Control-Allow-Headers
Default: "'*'"
Type: String
CorsHeaders:
Description: Header Access-Control-Allow-Headers
Default: "'Content-Type,X-Amz-Date,Authorization,X-Api-Key'"
Type: String
SwaggerS3File:
Description: 'S3 "swagger.yaml" file location'
Default: "./swagger.yaml"
Type: String
Resources:
LambdaRoleForRuleExecution:
Type: AWS::IAM::Role
Properties:
RoleName: !Sub ${AWS::StackName}-lambda-role
AssumeRolePolicyDocument:
Version: '2012-10-17'
Statement:
- Effect: Allow
Action: 'sts:AssumeRole'
Principal:
Service: lambda.amazonaws.com
Policies:
- PolicyName: WriteCloudWatchLogs
PolicyDocument:
Version: 2012-10-17
Statement:
- Effect: Allow
Action:
- 'logs:CreateLogGroup'
- 'logs:CreateLogStream'
- 'logs:PutLogEvents'
Resource: 'arn:aws:logs:*:*:*'
ApiGatewayStepFunctionsRole:
Type: AWS::IAM::Role
Properties:
Path: !Join ["", ["/", !Ref "AWS::StackName", "/"]]
AssumeRolePolicyDocument:
Version: 2012-10-17
Statement:
- Sid: AllowApiGatewayServiceToAssumeRole
Effect: Allow
Action:
- 'sts:AssumeRole'
Principal:
Service:
- apigateway.amazonaws.com
Policies:
- PolicyName: CallStepFunctions
PolicyDocument:
Version: 2012-10-17
Statement:
- Effect: Allow
Action:
- 'states:StartExecution'
Resource:
- !Ref Workflow
Start:
Type: AWS::Lambda::Function
Properties:
FunctionName: !Sub ${AWS::StackName}-start
Code: ../dist/src/step-functions
Handler: step-functions.start
Role: !GetAtt LambdaRoleForRuleExecution.Arn
Runtime: nodejs8.10
Timeout: 1
Wait3000:
Type: AWS::Lambda::Function
Properties:
FunctionName: !Sub ${AWS::StackName}-wait3000
Code: ../dist/src/step-functions
Handler: step-functions.wait3000
Role: !GetAtt LambdaRoleForRuleExecution.Arn
Runtime: nodejs8.10
Timeout: 4
Wait500:
Type: AWS::Lambda::Function
Properties:
FunctionName: !Sub ${AWS::StackName}-wait500
Code: ../dist/src/step-functions
Handler: step-functions.wait500
Role: !GetAtt LambdaRoleForRuleExecution.Arn
Runtime: nodejs8.10
Timeout: 2
End:
Type: AWS::Lambda::Function
Properties:
FunctionName: !Sub ${AWS::StackName}-end
Code: ../dist/src/step-functions
Handler: step-functions.end
Role: !GetAtt LambdaRoleForRuleExecution.Arn
Runtime: nodejs8.10
Timeout: 1
StateExecutionRole:
Type: AWS::IAM::Role
Properties:
AssumeRolePolicyDocument:
Version: '2012-10-17'
Statement:
- Effect: Allow
Principal:
Service:
- !Sub states.${AWS::Region}.amazonaws.com
Action:
- 'sts:AssumeRole'
Policies:
- PolicyName: "StatesExecutionPolicy"
PolicyDocument:
Version: "2012-10-17"
Statement:
- Effect: "Allow"
Action: "lambda:InvokeFunction"
Resource:
- !GetAtt Start.Arn
- !GetAtt Wait3000.Arn
- !GetAtt Wait500.Arn
- !GetAtt End.Arn
Workflow:
Type: AWS::StepFunctions::StateMachine
Properties:
StateMachineName: !Sub ${AWS::StackName}-state-machine
RoleArn: !GetAtt StateExecutionRole.Arn
DefinitionString: !Sub |
{
"Comment": "AWS Step Functions Example",
"StartAt": "Start",
"Version": "1.0",
"States": {
"Start": {
"Type": "Task",
"Resource": "${Start.Arn}",
"Next": "Parallel State"
},
"Parallel State": {
"Type": "Parallel",
"Next": "End",
"Branches": [
{
"StartAt": "Wait3000",
"States": {
"Wait3000": {
"Type": "Task",
"Resource": "${Wait3000.Arn}",
"End": true
}
}
},
{
"StartAt": "Wait500",
"States": {
"Wait500": {
"Type": "Task",
"Resource": "${Wait500.Arn}",
"End": true
}
}
}
]
},
"End": {
"Type": "Task",
"Resource": "${End.Arn}",
"End": true
}
}
}
RestApi:
Type: AWS::Serverless::Api
Properties:
StageName: !Ref Environment
Name: !Sub ${AWS::StackName}-api
DefinitionBody:
'Fn::Transform':
Name: AWS::Include
Parameters:
# s3 location of the swagger file
Location: !Ref SwaggerS3File
swagger.yaml
openapi: 3.0.0
info:
version: '1.0'
title: "pit-jv-lambda-examples"
description: POC API
license:
name: MIT
x-amazon-apigateway-request-validators:
Validate body:
validateRequestParameters: false
validateRequestBody: true
params:
validateRequestParameters: true
validateRequestBody: false
Validate body, query string parameters, and headers:
validateRequestParameters: true
validateRequestBody: true
paths:
/execute:
options:
x-amazon-apigateway-integration:
type: mock
requestTemplates:
application/json: |
{
"statusCode" : 200
}
responses:
"default":
statusCode: "200"
responseParameters:
method.response.header.Access-Control-Allow-Headers:
Fn::Sub: ${CorsHeaders}
method.response.header.Access-Control-Allow-Methods:
Fn::Sub: ${CorsMethods}
method.response.header.Access-Control-Allow-Origin:
Fn::Sub: ${CorsOrigin}
responseTemplates:
application/json: |
{}
responses:
200:
$ref: '#/components/responses/200Cors'
post:
x-amazon-apigateway-integration:
credentials:
Fn::GetAtt: [ ApiGatewayStepFunctionsRole, Arn ]
uri:
Fn::Sub: arn:aws:apigateway:${AWS::Region}:states:action/StartExecution
httpMethod: POST
type: aws
responses:
default:
statusCode: 200
responseParameters:
method.response.header.Access-Control-Allow-Headers:
Fn::Sub: ${CorsHeaders}
method.response.header.Access-Control-Allow-Origin:
Fn::Sub: ${CorsOrigin}
".*CREATION_FAILED.*":
statusCode: 403
responseParameters:
method.response.header.Access-Control-Allow-Headers:
Fn::Sub: ${CorsHeaders}
method.response.header.Access-Control-Allow-Origin:
Fn::Sub: ${CorsOrigin}
responseTemplates:
application/json: $input.path('$.errorMessage')
requestTemplates:
application/json:
Fn::Sub: |-
{
"input": "$util.escapeJavaScript($input.json('$'))",
"name": "$context.requestId",
"stateMachineArn": "${Workflow}"
}
summary: Start workflow
responses:
200:
$ref: '#/components/responses/200Empty'
403:
$ref: '#/components/responses/Error'
components:
schemas:
Error:
title: Error
type: object
properties:
code:
type: string
message:
type: string
responses:
200Empty:
description: Default OK response
200Cors:
description: Default response for CORS method
headers:
Access-Control-Allow-Headers:
schema:
type: "string"
Access-Control-Allow-Methods:
schema:
type: "string"
Access-Control-Allow-Origin:
schema:
type: "string"
Error:
description: Error Response
content:
application/json:
schema:
$ref: '#/components/schemas/Error'
headers:
Access-Control-Allow-Headers:
schema:
type: "string"
Access-Control-Allow-Origin:
schema:
type: "string"
step-functions.js
exports.start = (event, context, callback) => {
console.log('start event', event);
console.log('start context', context);
callback(undefined, { function: 'start' });
};
exports.wait3000 = (event, context, callback) => {
console.log('wait3000 event', event);
console.log('wait3000 context', context);
setTimeout(() => {
callback(undefined, { function: 'wait3000' });
}, 3000);
};
exports.wait500 = (event, context, callback) => {
console.log('wait500 event', event);
console.log('wait500 context', context);
setTimeout(() => {
callback(undefined, { function: 'wait500' });
}, 500);
};
exports.end = (event, context, callback) => {
console.log('end event', event);
console.log('end context', context);
callback(undefined, { function: 'end' });
};
$context.accountId
中获取账户ID,但是找不到任何可以提供当前区域名称的内容。在我的模板中,stateMachineArn现在看起来像这样,"arn:aws:states:us-east-1:$context.accountId:stateMachine:AbcStateMachine"
有什么想法可以让我动态获取当前区域吗? - rockyPeoplesChamp$data
只是使用请求正文的数据字段,如果我们以类似的方式传递name
字段,它将如何进入请求?因为它将在$data
内部。我尝试使用$data.name
,但它没有起作用。有什么想法吗? - ChumiestBucket
